ProLiant DL320 G3 Rackmount Server

Overview

1. Support for up to two SATA or SCSI non-hot plug hard drives
2. Fan Assembly, 4 NHP Dual Rotor Fans with N+1 Redundancy
3. Optional 1.44MB Diskette Drive Assembly Option Kit
4. Two PCI-X slots standard with an optional PCI Express slot
5. Optional CD-ROM/DVD-ROM Drive Assembly Option Kit
6. PC3200 DDR1 Memory Slots
7. Front LED Indicators
8. Power Supply

Main Features

• Several processor options to choose from:
  • Intel Celeron D Processor 340J 2.93 GHz/533MHz FSB 256KB Level 2 Cache
  • Intel Pentium 4 Processors with HT Technology and EM64T 3.4 GHz with 1M or 2M L2 Cache
  • Intel Pentium 4 Processors with HT Technology and EM64T 3.6 GHz with 1MB or 2MB Level 2 Cache (Factory Integrated Only)
• Up to 4GB of advanced ECC PC3200 DDR 400MHz SDRAM Memory
  • 1GB standard in all Pentium 4 models
  • 512 MB in Celeron D models
• Two available PCI-X slots, including one full-length 64-bit/133MHz slot and one half-length, low-profile 64-bit/100MHz slot
• Optional PCI-Express full-length slot
• Embedded NC7782 Dual Port PCI-X 10/100/1000T Gigabit network adapter
• Integrated iLO Remote Management
• HP embedded 2 Port SATA Controller with RAID 0/1 support
• 1U (1.70") Form Factor
• Optional CD,DVD, or CD-RW/DVD Combo drive and Floppy drive
• Four USB ports (1 front, 1 internal and 2 in rear)
• Intel E7221 Chipset with 800MHz Front Side Bus (533MHz for Celeron Processors)
• New spring-loaded Universal sliding rails for in rack servicing ship standard
• Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU), HP System Insight Manager, Status LEDs including system health and UID and SmartStart
• Internal Storage capacity of 500 GB (2 x 250 GB SATA hard drives) or 145.6 GB (2 x 72.8 GB SCSI or SAS hard drives)
• 350 Watt PFC Power Supply
• Internal USB port can also be used as internal USB port for leave-in USB key support
• Protected by HP Services and a worldwide network of resellers and service providers. Three-year Next Business Day, on-site limited global warranty. Certain restrictions and exclusions apply. Pre-Failure Notification on processors, memory, and SCSI hard drives. SATA hard drives have a one-year warranty.
