	ProLiant DL580 G3 Rackmount Server
	Overview

	Dual Hot Plug Redundant Power Supplies (one standard with 1P Models, requires optional RPS for redundancy) Up to Seven I/O Slots: 5 Standard 64-bit PCI-X (Three 133MHz and Two 100MHz). Optional Mezzanine adds Two Hot Plug 64-bit/133MHz PCI-X or two X4 PCI Express, or one X8 PCI Express 4U (7" Height) Rack Form Factor Server Lifting Handles SCSI Models ship with Smart Array 6i Ultra320 array controller with optional 128MB Battery Backed Write Cache (BBWC ships standard with some models) Universal Tool-less "Snap In" Sliding Rail Solution Wide Ultra3/U320 Duplex Drive Cage (can be Simplex configured) QuickFind Diagnostic Display Support for up to four 1" Ultra320 SCSI hot plug hard drives or two hot plug hard drives and one DAT 40 or DAT 72 hot plug tape drive Serial Attached SCSI(SAS) Model has support for up to 8 Small Form-Factor (SFF) SAS or Serial ATA (SATA) drives	Support for up to Two Slimline Drives (Ejectable, DVD Drive standard, Floppy Drive optional with all models) Front Panel LED Display (internal and external health, Two Network Port Status, Unit ID light) and Power Button One front accessible USB 2.0 port, Two rear accessible USB 2.0 ports (all bootable) Front accessible Processor drawer (allows access to Processors and Processor Power Modules) Support for up to four 64-bit Intel® Xeon™ MP Processors with 667 MHz FSB, and 0M-8M L3 cache Quick release levers for fast server access Front accessible Hot Plug RAID Memory (One Memory Board ships Standard with all models) Six Hot Plug Redundant Fans Standard on all models Quick Removal Access Panel
	Main Features
	New HP ProLiant DL580 G3 features: Supports up to four 64-bit Intel® Xeon™ MP processors and HT Technology, Dual Independent 667MHz Front Side Buses and up to 8MB of L3 cache Intel 8500 Chipset Front accessible Hot Plug RAID Memory (Configurable for Standard, Mirrored or RAID) provides maximum up-time, flexibility and serviceability Front accessible Processor and Processor Power Modules allow server to stay safely secured in the rack during servicing New HP Power Regulator for ProLiant delivering server level, policy based power management with industry leading energy efficiency and savings on system power and cooling costs Integrated Lights-Out support for Power Regulator for ProLiant and introducing support for the draft DMTF System Management Architecture for Server Hardware Command Line Protocol standard Rear accessible Hot Plug Redundant Power Supplies (RPS optional on some models) Up to Seven I/O Slots: 5 Standard 64-bit PCI-X (Three 133MHz and Two 100MHz). Optional Mezzanine adds Two Hot Plug 64-bit/133MHz PCI-X, Two X4 PCI Express, or One X8 PCI Express PC2-3200R 400MHz DDR2 Memory can be configured in Hot Plug Mirrored, Hot Plug RAID, Online Spare or Advanced ECC modes SCSI Models include integrated Ultra320 Smart Array 6i Controller with 64MB RAM and optional 128MB Battery-Backed Write Cache (BBWC) Enabler option kit SAS Models include Smart Array P600 Controller and 8-bay SAS Cage Option. Embedded NC7782 Dual Port PCI-X 10/100/1000 Gigabit NIC USB 2.0 up front, 2 ports rear (configurable for boot capability) Quick Deploy Rail System includes sliding universal rails, an ambidextrous cable management arm and quick release levers for fast and easy serviceability and in-rack tool-less access to major components New iLO Shared Network Port enables access to the iLO management processor through one of the embedded system NIC's (Can be disabled). This allows access to iLO without requiring a separate, dedicated network connection for iLO. Slimline DVD Drive standard, Floppy Drive optional on all models (ejectable) HP ProLiant DL580 G3 features, that were also included in the HP ProLiant DL580 G2: Integrated Lights-Out (iLO) Standard Management on system board Simplex or Duplex configurable Wide Ultra3/U320 Duplex Drive Cage Support for up to four 1" Ultra320 SCSI hot plug hard drives or three hot plug hard drives and one DAT hot plug tape drive Hot Plug Fans with full redundancy Tool-less access to all system components for easy in rack serviceability Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU), HP Systems Insight Manager, Status LED's including system health and UID, and SmartStart Internal hot plug hard drive capacity 1.2 TB standard (4 x 300 GB 1" HD) Protected by HP Services and a worldwide network of resellers and service providers. Three-year Next Business Day, on-site limited global warranty. Certain restrictions and exclusions apply. Pre-Failure Notification on processors, memory, and SCSI hard drives. SATA hard drives have a one-year warranty.
