ProLiant DL570 G2 Full Tower Server

Overview

1. 1.44-MB Diskette Drive
2. High Speed IDE CD-ROM
3. Diagnostic Lighting
4. Wide Ultra3/Ultra320 Hot Plug Drive Bays (12 x 1" Standard)

5. Front Bezel
6. 5.25-inch Removable Media Bays
7. Seven PCI-X slots
8. Memory Board

1. Rack handles
2. 1.44-MB Diskette Drive
3. High Speed IDE CD-ROM

4. Diagnostic Lighting
5. Wide Ultra3/Ultra320 Hot Plug Drive Bays (12 x 1" Standard)
6. 5.25-inch Removable Media Bays

Main Features

• Intel® Xeon Processors MP 3.0 GHz/4MB, 2.7 GHz/2MB or 2.2 GHz/2MB
• Best-in-class 4-way server with exceptional performance, maximum reliability and unmatched expansion/flexibility
• ServerWorks Grand Champion-HE chipset
• 2x1 interleaved memory, 200MHz DDR SDRAM Memory
• 1024 MB PC1600 Advanced ECC SDRAM Memory standard, expandable to 32 GB
• Seven, full length 64-bit/100 MHz PCI-X slots, 4 Hot Pluggable
• Integrated NC3163 Fast Ethernet NIC PCI 10/100 WOL (Wake On LAN) and PXE support
• Integrated Dual Channel Wide Ultra3 compatible SCSI Adapter
• Wide Ultra3 compatible SCSI Drive Cage standard (two 6 x 1" cages)
• Internal mass storage capacity up to 4.20 TB (12 x 300 GB + 2 x 300 GB 1" hot plug drives) with optional ML5xx Internal Two Bay Hot Plug SCSI Drive Cage (with Fan)
• Support for DAT hot plug tape drives
• Integrated Remote Console and Automatic Server Recovery-2 (ASR-2)
• Two 600-Watt Hot Pluggable Power Supplies (additional third for redundancy)
• Optional Redundant Hot Plug Fans
• Industry-standard PCI Hot Plug with Push Button Functionality
• Advanced Memory Protection including Online Spare Memory, Hot-plug Mirrored memory and hot-add capability
• Protected by HP Services and a worldwide network of resellers and service providers. Three-year Next Business Day, on-site limited global warranty. Certain restrictions and exclusions apply. Pre-Failure Notification on processors, memory, and SCSI hard drives.
